Square D by Schneider Electric HDL36060 PowerPacT H Frame Circuit Breaker with Thermal-Magnetic Trip Unit Technology, 60 Amp, 3 Pole
Product details
| Management number | 220663580 | Release Date | 2026/05/03 | List Price | US$176.22 | Model Number | 220663580 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 14kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 60A, 3 pole, circuit breaker has a breaking capacity of 14kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
- ROBUST CIRCUIT PROTECTION: PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits; Dual-break rotating contacts that reduce the amount of peak current during a short circuit fault
- THERMAL MAGENTIC PROTECTION: Thermal-magnetic protection provides thermal protection against overload and instantaneous protection against short circuits for general-purpose applications
- MANUAL TRIP FUNCTION: PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker
- LUGS: This unit has lugs on both the line and load sides for convenient cable connections
- SPECIFICATIONS AND CERTIFICATIONS: This PowerPacT H-Frame 60A 3 pole circuit breaker has a breaking capacity of 14kA at 600VAC; Continuous current rating - 80%; Complies to UL, CSA, NOM, and IEC standards; CE marked; Covered by 18-Month Warranty
| UPC | 785901577959 |
|---|---|
| Model | HDL36060 |
| Voltage | 600 Volts |
| Brand Name | Schneider Electric |
| Unit Count | 1.0 Count |
| Item Weight | 4.1 Pounds |
| Part Number | HDL36060 |
| Manufacturer | Schneider Electric |
| Mounting Type | lugs |
| Current Rating | 60 Amps |
| Item Type Name | SCHNEIDER ELECTRIC HDL36060 MOLDED CASE CIRCUIT BREAKER 600V 60A |
| Number of Poles | 3 |
| Included Components | HDL36060 |
| Circuit Breaker Type | Standard |
| Warranty Description | No Warranty |
| Smart Home Compatibility | Not Smart Home Compatible |
| Item Dimensions D x W x H | 3.39"D x 4.09"W x 6.42"H |
| Global Trade Identification Number | 00785901577959 |
